Parallel and/or LAzY Analyzer for PDF 🏖️

About

There are already too many PDF libraries, unfortunately none of which does everything that everybody wants it to do, and we probably don't need another one. It is not recommended that you use this library for anything at all, but if you were going to use it for something, it might be one of these things, which you may currently be doing with pdfminer.six, for instance:

  1. Accessing the document catalog, page tree, structure tree, outline, content streams, cross-reference table, XObjects, fonts, images, annotations, and other low-level PDF metadata.
  2. Obtaining the absolute position and attributes of every character, line, path, and image in every page of a PDF.

Note that while PLAYA Ain't a LAYout Analyzer, it does in fact implement the layout analysis algorithm from pdfminer.six anyways. See the documentation for more information on how to migrate your code. You may be interested to know that PLAYA's implementation is also 15-50% faster, depending on how many CPUs you use.

All that said, the primary purpose of PLAYA is to provide a parallel, parallelizable, pure-Python and Pythonic (for its author's definition of the term), lazy interface to the internals of PDF files.

But, it does more than that! It also includes a command-line interface which can dump out various types of PDF data and metadata quickly. For instance, you might want to dump out all the PDF operators in all the content streams on all the pages:

playa --content-streams my-awesome-document.pdf

Or you could look at the document outline or logical structure tree:

playa --outline some-interesting-stuff.pdf
playa --structure tagged-pdf-wow.pdf

And, yes, it does extract text, or also text objects (with associated metadata):

playa --text fascinating-research-paper.pdf
playa --text-objects colorful-presentation.pdf

Or images, in JPEG and PNM (or sometimes TIFF) format (may not work for all images):

playa --images imagedir splashy-resume.pdf

Or fonts, in various esoteric formats (may not work for all fonts):

playa --fonts fontdir typographic-horror.pdf

If you just want to extract text from a PDF, there are better and/or faster tools and libraries out there, notably pypdfium2 and pypdf, among others. See these benchmarks for a comparison. Nonetheless, you will notice in this comparison that:

  • PLAYA (using 2 CPUs) is the fastest pure-Python PDF reader by far
  • PLAYA has no dependencies and no C++
  • PLAYA is MIT licensed

PLAYA is also very good at reading logical structure trees. On my town's 486-page zoning bylaw, extracting the entire tree with its text contents as JSON using playa --structure takes only 23 seconds, whereas pdfplumber --structure-text takes 69 seconds and pdfinfo -struct-text (which doesn't output JSON) takes 110 seconds.

I cannot stress this enough, text extraction is not the primary use case for PLAYA, because extracting text from PDFs is not fun, and I like fun. Do you like fun? Then read on.

Installation

Installing it should be really simple as long as you have Python 3.8 or newer:

pipx install playa-pdf

Yes it's not just "playa". Sorry about that. If you wish to read certain encrypted PDFs then you will need the crypto add-on:

pipx install playa-pdf[crypto]

Usage

Do you want to get stuff out of a PDF? You have come to the right place! Let's open up a PDF and see what's in it:

pdf = playa.open("my_awesome_document.pdf")
raw_byte_stream = pdf.buffer
a_bunch_of_tokens = list(pdf.tokens)
a_bunch_of_indirect_object_ids = list(pdf.keys())
a_bunch_of_indirect_objects = list(pdf.values())
a_bunch_of_pages = list(pdf.pages)

Yes, a Document is fundamentally a Mapping of object IDs to objects, which are represented to the extent possible by native Python objects. These may not be terribly useful to you, but you might find them interesting. Note that these are "indirect objects" where the actual object is accompanied by an object number and "generation number". If you wish to find all the objects in a PDF file, then you will need to iterate over the objects property:

for indobj in pdf.objects:
    objid, genno, obj = indobj

It is possible you will encounter multiple objects with the same objid due to the "incremental updates" feature of PDF. As expected, you can subscript the document to access indirect objects by number (this will return the object with most recent generation number):

a_particular_object = pdf[42]

Your PDF document probably has some pages. How many? What are their numbers/labels? They could be things like "xvi" (pronounced "gzvee"), 'a", or "42", for instance!

npages = len(pdf.pages)
page_numbers = [page.label for page in pdf.pages]

You can also subscript pages in various other ways, using a slice or an iterable of int, which will give you a new page list object that behaves similarly. Pages and page lists can refer back to their document (using weak reference magic to avoid memory leaks) with their doc property.

Some (by no means all) helpful metadata

A PDF often contains a "document outline" which is a sequence of trees representing the coarse-grained logical structure of the document, accessible via the outline property:

for entry in pdf.outline:
    entry.title, entry.destination, entry.action, entry.element
    for child in entry:
        child.title, child.destination, child.action, child.element
        ...

If you are lucky it has a "logical structure tree". The elements here might even be referenced from the outline above! (or, they might not... with PDF you never know).

for element in pdf.structure:
   for child in element:
       ...
sections = structure.find_all("Sect")
first_p = structure.find("P")

Now perhaps we want to look at a specific page. Okay! You can also look at its contents, more on that in a bit:

page = next(iter(pdf.pages)) # Fast and lazy way to get the first page
page = pdf.pages[0]          # they are numbered from 0
page = pdf.pages["xviii"]    # but you can get them by label (a string)
page = pdf.pages["42"]       # or "logical" page number (also a string)
print(f"Page {page.label} is {page.width} x {page.height}")

Since PDF is at heart a page-oriented, presentation format, many types of metadata are mostly accessible via the page objects. For instance you can access the fonts used in page with, obviously, the fonts property, or the annotations via the annotations property.

For example, annotations (internal or external links) are defined on pages (since their position would not make any sense otherwise). There are umpteen zillion kinds of annotations (PDF 1.7 sect 12.5.6) but they all have at least these attributes in common:

for annot in page.annotations:
    annot.subtype, annot.rect, annot.props

The set of possible entries in annotation dictionaries (PDF 1.7 sect 12.5.2) is vast and confusing and inconsistently implemented. You can access the raw annotation dictionary via props in the Annotation object.

If the document has logical structure, then the pages will also have a slightly different form of logical structure. You can use the find and find_all methods to get all of the enclosing structure elements of a given type (actually a role) for a page. So for instance if you wanted to get the text contents for all the cells in all the tables on a page, assuming the creator of said page was kind enough to check the "PDF/UA" box, you can do:

for table in page.structure.find_all("Table"):
    print(f"Table at {table.bbox}: {[x.text for x in table.contents]}")

Accessing content

What are these "contents" of which you speak, which were surely created by a Content Creator? Well, you can look at the stream of tokens or mysterious PDF objects:

for token in page.tokens:
    ...
for object in page.contents:
    ...

But that isn't very useful, so you can also access actual textual and graphical objects (if you wanted to, for instance, do layout analysis).

for item in page:
    ...

Because it is quite inefficient to expand, calculate, and copy every possible piece of information, PLAYA gives you some options here. Wherever possible this information can be computed lazily, but this involves some more work on the user's part.

Using multiple CPUs

You may be wondering, what does "Parallel and Lazy" really mean? PLAYA allows you to take advantage of multiple CPUs, which can greatly speed up some operations on large documents. This parallelism currently operates at the page level since this is the most logical way to split up a PDF. To enable it, pass the max_workers argument to playa.open with the number of cores you wish to use (you can also explicitly pass None to use the maximum):

with playa.open(path, max_workers=4) as pdf:
    ...

Now, you can apply a function across the pages of the PDF in parallel using the map method of pdf.pages, for example:

def get_page_size(page: Page) -> Tuple[int, int]:
    return page.width, page.height

page_sizes = pdf.pages.map(get_page_size)

You could also just do this for certain pages by subscripting pdf.pages (this can be a slice, an iterable of int, or a generator expression over int and/or str):

some_page_sizes = pdf.pages[2:5].map(get_page_size)

There are some limitations to this, because it uses multiprocessing. The function you pass to map must be serializable by pickle, which in practice means that an inner function or lambda generally doesn't work. You can get around this in a very Java-like way by passing a callable object that encapsulates the necessary state. If you wish to avoid traumatising readers of your code, then use functools.partial instead:

pdf.pages.map(partial(myfunc, arg1=value1, arg2=value2))

Also, any value returned by your function must also be serializable. There is a bit of magic that enables this to work for PDF objects containing indirect object references, so you should be able to, for instance, get the annotations from every page without any trouble. But if you have your own complex objects that you return you may encounter problems (or slowness).

An important note about coordinate spaces

Wait, what is this "absolute position" of which you speak, and which PLAYA gives you? It's important to understand that there is no definition of "device space" in the PDF standard, and I quote (PDF 1.7 sec 8.3.2.2):

A particular device’s coordinate system is called its device space. The origin of the device space on different devices can fall in different places on the output page; on displays, the origin can vary depending on the window system. Because the paper or other output medium moves through different printers and imagesetters in different directions, the axes of their device spaces may be oriented differently.

You may immediately think of CSS when you hear the phrase "absolute position" and this is exactly what PLAYA gives you as its default device space, specifically:

  • Units are default user space units (1/72 of an inch).
  • (0, 0) is the top-left corner of the page, as defined by its MediaBox after rotation is applied.
  • Coordinates increase from the top-left corner of the page towards the bottom-right corner.

However, for compatibility with pdfminer.six, you can also pass space="page" to playa.open. In this case, (0, 0) is the bottom-left corner of the page as defined by the MediaBox, after rotation, and coordinates increase from the bottom-left corner of the page towards the top-right, as they do in PDF user space.

If you don't care about absolute positioning, you can use space="default", which may be somewhat faster in the future (currently it isn't). In this case, no translation or rotation of the default user space is done (in other words any values of MediaBox or Rotate in the page dictionary are simply ignored).

In general, where the API provides you with coordinates, they are translated to the device space, unless indicated otherwise (for example, sometimes there is a rect property which gives the default user-space rectangle, and a bbox property which gives device space).

Lazy object API

Fundamentally you may just want to know what is where on the page, and PLAYA has you covered there (note that the bbox is normalized, and in the aforementioned interpretation of "device space"):

for obj in page:
    print(f"{obj.object_type} at {obj.bbox}")

    # With space="screen" (the default)
    left, top, right, bottom = obj.bbox
    print(f"  top left is {left, top}")
    print(f"  bottom right is {right, bottom}")

    # With space="page" or space="default"
    left, bottom, right, top = obj.bbox
    print(f"  bottom left is {left, bottom}")
    print(f"  top right is {right, top}")

Another important piece of information (which pdfminer.six does not really handle) is the relationship between layout and logical structure, done using marked content sections:

for obj in page:
    print(f"{obj.object_type} is in marked content section {obj.mcs.mcid}")
    print(f"    which is tag {obj.mcs.tag.name}")
    print(f"    with properties {obj.mcs.tag.props}")
    print(f"    in structure element {obj.parent}")

The mcid here is the same one referenced in elements of the structure tree as shown above (but remember that tag has nothing to do with the structure tree element, because Reasons). Logical structure elements can contain one or more marked content sections, and the parent element can be found using the parent property on content objects or the structure property on pages and Form XObjects, which contains them indexed by mcid.

A marked content section does not necessarily have a mcid or props, but it will always have a tag. Exceptionally, because marked content sections may (unfortunately) be nested, you can find the mcid of the nearest containing marked content section, if one exists, with the mcid property on objects.

PDF also has the concept of "marked content points". PLAYA suports these with objects of object_type == "tag". The tag name and properties are also accessible via the mcs attribute.

You may also wish to know the complete stack of enclosing marked content sections. This is accessible from the mcstack property. Note that though it's called a "stack", it's actually a tuple. This means that it is immutable, and you can check if it has changed from one object to the next using the is operator.

All content objects can also refer back to their containing Page from the page property. This uses weak reference magic in order to avoid causing memory leaks.

Form XObjects

A PDF page may also contain "Form XObjects" which are like tiny embedded PDF documents (they have nothing to do with fillable forms). Simply iterating over a Page will not expand these for you which may be a source of surprise, but you can recurse into them with the flatten method, or with the convenience properties paths, images, texts and glyphs. You can also identify them in iteration because they have object_type == "xobject". The layout objects inside are accessible by iteration, as with pages:

for obj in page:
    if obj.object_type == "xobject":
        for item in obj:
            ...

You can also iterate over them in the page context with page.xobjects (this will also find Form XObjects contained inside other Form XObjects, which is unfortunately a thing):

for xobj in page.xobjects:
    for item in xobj:
        ...

Exceptionally, these have a few more features than the ordinary ContentObject - you can look at their raw stream contents as well as the tokens, and you can also see raw, mysterious PDF objects with contents.

Graphics state

You may also wish to know what color an object is, and other aspects of what PDF refers to as the graphics state, which is accessible through obj.gstate. This is a mutable object, and since there are quite a few parameters in the graphics state, PLAYA does not create a copy of it for every object in the layout. If you wish to reuse these objects, you should call finalize on them, which will freeze the graphics state and any other necessary context, allowing the object to be stored and reused as long as the document exists:

for obj in page:
    print(f"{obj.object_type} at {obj.bbox} is:")
    print(f"    {obj.gstate.scolor} stroking color")
    print(f"    {obj.gstate.ncolor} non-stroking color")
    print(f"    {obj.gstate.dash} dashing style")
    object_of_interest = obj.finalize()
print("interesting object:", playa.asobj(obj))

You should thus be aware that storing content objects to a list, then iterating over that list, will give unpredictable and undefined results! Don't do this:

objs = list(page)  # DO NOT do this

Do this instead:

objs = [obj.finalize() for obj in page]  # DO this instead

Path Objects

Unlike pdfminer.six, PLAYA does not try to interpret paths (as rectangles or whatever) nor does it break them into "subpaths". You just get path segments (it does, however, do some basic normalization to remove redundant segments). You can look at the actual path segments in user space (fast):

for seg in path.raw_segments:
   print(f"segment: {seg}")

Or in PLAYA's "device space" (not so fast):

for seg in path.segments:
   print(f"segment: {seg}")

Text Objects

Since most PDFs consist primarily of text, obviously you may wish to know something about the actual text (or the ActualText, which you can sometimes find in obj.mcs.tag.props["ActualText"]). This is more difficult than it looks, as fundamentally PDF just positions arbitrarily numbered glyphs on a page, and the vast majority of PDFs embed their own fonts, using subsetting to include only the glyphs actually used.

Whereas pdfminer.six would break down text objects into their individual glyphs (which might or might not correspond to characters), this is not always what you want, and moreover it is computationally quite expensive. So PLAYA, by default, does not do this. If you don't need to know the actual bounding box of a text object, then don't access obj.bbox and it won't be computed. If you don't need to know the position of each glyph but simply want the Unicode characters, then just look at obj.chars.

It is also important to understand that obj.chars may or may not correspond to the actual text that a human will read on the page. To actually extract text from a PDF necessarily involves Heuristics or Machine Learning. PLAYA has some simple heuristics to do this, which will work better with tagged and accessible PDFs, but don't expect miracles.

This is because PDFs, especially ones produced by OCR, don't organize text objects in any meaningful fashion, so you will want to actually look at the glyphs. This becomes a matter of iterating over the item, giving you, well, more items, which are the individual glyphs:

for glyph in item:
    print("Glyph has CID {glyph.cid} and Unicode {glyph.text}")

Note that the actual positioning of the glyphs is only done once you actually look at their bbox property, so for instance, if you wish to ignore glyphs with glyph.gstate.render_mode == 3 (which means "invisible") or glyph.gstate.scolor.values == (1.0,) (which means "written in white ink") then you could do that.

For text extraction you really don't care about the bbox, but you probably do care about the origin of each glyph relative to its neighbours. For this reason PLAYA provides you with two convenience properties, origin. and displacement, which are considerably faster to compute than the bbox.

PLAYA doesn't guarantee that text objects come at you in anything other than the order they occur in the file (but it does guarantee that).

An important note about text objects

But wait! What do we mean by "Text Objects"? What is "text", anyway? While philosophers have debated this question for millennia, PDF has a somewhat more precise definition (PDF 1.7, sec 9.4.1):

A PDF text object consists of operators that may show text strings, move the text position, and set text state and certain other parameters ... A text object begins with the BT operator and ends with the ET operator ... specific categories of text-related operators may appear in a text object ...

Except that this is not entirely true! Many other operators may also appear in a text object (PDF 1.7, sec 8.2, table 9):

Text object: Allowed operators:

  • General graphics state
  • Color
  • Text state
  • Text-showing
  • Text-positioning
  • Marked-content

In other words, as usual:

Adobe is Spiderman

(above meme does not apply to PDF 2.0, where you, yes you, can help to eradicate the numerous inconsistencies, contradictions, and ambiguities of the previous standard)

In particular, we care a lot about marked content operators, because of the abovementioned ActualText property. For this reason a TextObject in PLAYA does not and will never correspond to a PDF text object as defined by the BT and ET operators. For the moment, every text-showing operator triggers a new TextObject. It is possible (though unlikely) that in the future, only changes in marked content or graphics state will do this.

Conclusion

As mentioned earlier, if you really just want to do text extraction, there's always pdfplumber, pymupdf, pypdfium2, pikepdf, pypdf, borb, etc, etc, etc.

Acknowledgement

This repository obviously includes code from pdfminer.six. Original license text is included in LICENSE. The license itself has not changed!

For the moment PLAYA is developed and maintained by David Huggins-Daines.
